Description
Camera
- Image Sensor – 2 MP CMOS
- Max. Resolution – 1920 (H) × 1080 (V)
- Min. Illumination – 0.02 Lux @ (F2.2, AGC ON), 0 Lux with IR
- Shutter Time – PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Day ＆ Night – ICR
- Angle Adjustment – Pan: 0 to 360°, Tilt: 0 to 90°, Rotate: 0 to 360°
- Signal System – PAL/NTSC
Lens
- Lens Type – 2.8 mm, 3.6 mm fixed focal lens
- Focal Length ＆ FOV –
- 2.8 mm, horizontal FOV: 97°, vertical FOV: 54°, diagonal FOV: 113°
- 3.6 mm, horizontal FOV: 77°, vertical FOV: 43°, diagonal FOV: 90°
- Lens Mount – M12
Illuminator
- Supplement Light Type – White Light,IR
- Supplement Light Range –
- IR : Up to 20 m
- White Light : Up to 20 m
- Image Parameters Switch – STD/HIGH-SAT/HIGHLIGHT
- Image Settings – Brightness, Sharpness, Smart IR
- Frame Rate –
TVI: 1080p @ 30 fps, 1080p @ 25 fps
AHD: 1080p @ 30 fps, 1080p @ 25 fps
CVI: 1080p @ 30 fps, 1080p @ 25 fps
CVBS: PAL/NTSC - Wide Dynamic Range (WDR) – Digital WDR
- Image Enhancement – DWDR/BLC/HLC/Global
- White Balance – Auto/Manual
- AGC – Yes
Interface
- Video Output – Switchable TVI/AHD/CVI/CVBS
General
- Material – Plastic
- Dimension – Ø 70 mm × 138.8 mm (Ø 2.76″ x 5.46″)
- Weight – Max. 150 g (0.33 lb.)
- Operating Condition – -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
- Communication – HIKVISION-C
- Language – English
- Power Supply – 12 VDC ± 25%, Max. 3.2 W
*You are recommended to use one power adapter to supply the power for one camera.
Approval
Protection – IP67
Accessory (Optional)
- DS-1280ZJ-XS – Junction box
- DS-2280ZJ -Wall mount
